Application:End Mills, Drills, Cutting Tools
Material:100% Original Tungsten Carbide
Tolerance:h6
Having all kind sizes for your choose,can suply less than 1000mm length.
Sintere by vacuum sintering furnace and HIP machine with excellent specifications without any hole.
Solid rod, one hole rod ,two straight holes rod ,two 30° helical holes
We have unground rod instock ,also can grounding outdiameter H5,H6,H7,h6,h5,h7 etc
We have diferent hardnesses for choose: 84.5HRA-94.1HRA, the more details refer our follow grades.
Grain sizes: 0.2um , 0.4um ,0.6um, 0.7um etc
Grades choosing
| Grade | Density (g/cm3) | Hardness (HRA) | T.R.S (MPa) | Grain size (μm) | Composition (%) |
| YG10X | 14.4 | ≥90.8 | ≥3600 | 0.6 | 10% CO 90% WC |
| YL10.2 | 14.45 | ≥91.8 | ≥3800 | 0.7 | 10% CO 90% WC |
| KSU610 | 14.45 | ≥92.2 | ≥4000 | 0.6 | 10% CO 90% WC |
| KUP25 | 14.12 | ≥92.5 | ≥4200 | 0.4 | 12%Co 88% WC |
| KUP409 | 14.5 | ≥93.2 | ≥4000 | 0.5 | 8%Co 92% WC |
| KUP10 | 14.8 | ≥94.1 | ≥3800 | 0.4 | 6% CO 94%WC |
| KUP209 | 14.45 | ≥94.0 | ≥4200 | 0.2 | 9% CO 91%WC |
| KUP30 | 13.98 | ≥89.0 | ≥4500 | 0.7 | 15% CO 85%WC |
